PET Oil free Compressor SZL Series 15-25m3/min

Model:SZL

Data range:42bar

24hour non stop
Water cooling oil free compress(ISO8573-1Standard)
Easy installation

market@szcompressor.com

Oil free warranty

The oil content is 0 grade,comply with the 8573-1 standard.

High-efficient design

The energy cost would reduce under the same condition.

Steady and low noise

The vibration is very little for the main machine,the noise could be 80dB(A).

Maintenance Period

6000-8000hours non stop running

Easy installation

Skid-mounted machine,achieve start,load,unload and stop by one key.

Parameter of SZL series:

Model

FAD m3/min Pressure MPa Speed r.p.m Size L×W×H mm Power KW Weight KG

Notes

SZL-15/40 15.0 3.0-4.2 530 4705X1920×2738 160 8800
SZL -16/40 16.0 590 185 9000
SZL -18/40 18.0 600 200 9200
SZL -20/40 20.0 400 5240X2225X2940 200 13000
SZL -22/40 22.0 440 220 14000
SZL -25/40 25.0 500 250 15000
SZVL-15/40 7.5-15.0 530 4705X1920×2738 160 9000

VSD

SZVL -16/40 8.0-16.0 590 185 9200
SZVL -18/40 9.0-18.0 600 200 9500
SZVL -20/40 10.0-20.0 400 5240X2225X2940 200 13500
SZVL -22/40 11.0-22.0 440 220 14500
SZVL -25/40 12.0-25.0 500 250 15500

Notes:

1.Performance parameters measured according to ISO2017,reference conditions:inlet temperature 20℃,inlet pressure 1barA

2.Special models could be customized.
